HPE ProLiant ML110 Gen10 - tower - Xeon Silver 4210R 2.4 GHz - 16 GB - no HDD

$5,536.00

MAIN SPECIFICATIONS

Product Description	HPE ProLiant ML110 Gen10 - tower - Xeon Silver 4210R 2.4 GHz - 16 GB - no HDD
Type	Server - tower
Height (Rack Units)	4.5U
Server Scalability	1-way
Processor	1 x Intel Xeon Silver 4210R / 2.4 GHz (3.2 GHz) (10-core)
Processor Main Features	Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache
Cache Memory	13.75 MB L3 cache
Cache Per Processor	13.75 MB
RAM	16 GB (installed) / 192 GB (max) - DDR4 SDRAM
Storage Controller	RAID (SAS 12Gb/s) - PCIe 3.0 x8 (Smart Array P408i-p SR)
Server Storage Bays	Hot-swap 2.5"
Hard Drive	No HDD
Optical Storage	No optical drive
Video Memory	16 MB
Networking	GigE
Power	AC 120/230 V (50/60 Hz)
Dimensions (WxDxH)	7.7 in x 18.9 in x 17.3 in
Weight	29.76 lbs
Environmental Standards	ENERGY STAR Qualified
Manufacturer Warranty	Limited warranty - parts and labor - 3 years - on-site

EXTENDED SPECIFICATIONS

General

Type	Server
Product Form Factor	Tower - 4.5U
Server Scalability	1-way
Front Accessible Bays Qty	1
Hot-Swap Bays Qty	8

Processor / Chipset

CPU	Intel Xeon Silver 4210R / 2.4 GHz
Max Turbo Speed	3.2 GHz
Number of Cores	10-core
CPU Qty	1
Max CPU Qty	1
CPU Upgradability	Upgradable
Processor Main Features	Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache
Chipset Type	Intel C621

Cache Memory

Installed Size	L3 cache - 13.75 MB
Cache Per Processor	13.75 MB

RAM

Installed Size	16 GB / 192 GB (max)
Technology	DDR4 SDRAM
Effective Memory Speed	2400 MHz
Rated Memory Speed	2933 MHz
Form Factor	DIMM 288-pin
Slots	6 (total) / 5 (empty)
Features	Registered
Configuration Features	1 x 16 GB
RAM Supported	PC4-21300 - 192 GB registered

Hard Drive

Type

No HDD

Storage Controller

Type	1 x RAID - PCIe 3.0 x8
Controller Interface Type	SAS 12Gb/s
Storage Controller Name	Smart Array P408i-p SR
Channel Qty	8
RAID Level	RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Buffer Size	2 GB

Optical Storage

Type	No optical drive

Monitor

Monitor Type

None.

Graphics Controller

Video Memory	16 MB
Video Interfaces	VGA

Networking

Ethernet Ports	2 x Gigabit Ethernet
Ethernet Controller	HPE 332i
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller	Integrated Lights-Out 5
Features	Wake on LAN (WoL), PXE support

Expansion / Connectivity

Bays	1 (total) / 1 (free) x external ¦ 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots	2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height (x4 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - three-quarter-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal) ¦ 1 (total) / 0 (free) x PCIe 3.0 x8 - half-length, full-height
Interfaces	1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 5 x USB 3.0 (2 front, 2 rear, 1 internal) ¦ 3 x USB 2.0 (2 rear, 1 internal) ¦ 1 x HPE iLO - Type A (1 in front)

Miscellaneous

Compliant Standards

WEEE, PCI DSS, ASHRAE Class A3, ACPI 6.1

Power

Device Type	Power supply - hot-plug
Installed Qty	1
Voltage Required	AC 120/230 V (50/60 Hz)
Power Provided	800 Watt
80 PLUS Certification	80 PLUS Platinum

Operating System / Software

Software

HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)

Environmental Standards

ENERGY STAR Certified	Yes
ENERGY STAR Version	2.1

Manufacturer Warranty

Service & Support

Limited warranty - parts and labor - 3 years - on-site

Dimensions & Weight

Width	7.7 in
Depth	18.9 in
Height	17.3 in
Weight	29.76 lbs

Environmental Parameters

Min Operating Temperature	50 °F
Max Operating Temperature	95 °F
Humidity Range Operating	8 - 90% (non-condensing)
Sound Emission	24.1 dBA
