HPE ProLiant DL380 Gen10 Network Choice - rack-mountable - Xeon Silver 4214R 2.4 GHz - 32 GB - no HDD
HPE ProLiant DL380 Gen10 Network Choice - rack-mountable - Xeon Silver 4214R 2.4 GHz - 32 GB - no HDD
HP

HPE ProLiant DL380 Gen10 Network Choice - rack-mountable - Xeon Silver 4214R 2.4 GHz - 32 GB - no HDD

Regular price $5,632.00 $0.00

MAIN SPECIFICATIONS

Product Description HPE ProLiant DL380 Gen10 Network Choice - rack-mountable - Xeon Silver 4214R 2.4 GHz - 32 GB - no HDD
Type Server - rack-mountable
Height (Rack Units) 2U
Localization Region: Worldwide (excluding China, Japan)
Server Scalability 2-way
Processor 1 x Intel Xeon Silver 4214R / 2.4 GHz (3.5 GHz) (12-core)
Processor Socket FCLGA3647 Socket
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2
Cache Memory 16.5 MB L3 cache
Cache Per Processor 16.5 MB
RAM 32 GB (installed) / 1.5 TB (max) - DDR4 SDRAM - Advanced ECC
Storage Controller RAID (SATA 6Gb/s / SAS 12Gb/s) - PCIe 3.0 x8 (HPE Smart Array P408i-a SR Gen10)
Server Storage Bays Hot-swap 2.5"
Hard Drive No HDD
Optical Storage No optical drive
Video Memory 16 MB
Networking GigE
Power AC 120/230 V (50/60 Hz)
Power Redundancy Optional
Dimensions (WxDxH) 17.5 in x 28.8 in x 3.4 in
Weight 32.54 lbs
Manufacturer Warranty Limited warranty - parts and labor - 3 years - on-site

EXTENDED SPECIFICATIONS

General
Type Server
Product Form Factor Rack-mountable - 2U
Server Scalability 2-way
Hot-Swap Bays Qty 8
Localization Region: Worldwide (excluding China, Japan)
Processor / Chipset
CPU Intel Xeon Silver 4214R / 2.4 GHz
Max Turbo Speed 3.5 GHz
Number of Cores 12-core
CPU Qty 1
Max CPU Qty 2
CPU Upgradability Upgradable
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology 2
CPU Socket FCLGA3647 Socket
Chipset Type Intel C621
Cache Memory
Installed Size L3 cache - 16.5 MB
Cache Per Processor 16.5 MB
RAM
Installed Size 32 GB / 1.5 TB (max)
Technology DDR4 SDRAM - Advanced ECC
Effective Memory Speed 2400 MHz
Rated Memory Speed 2933 MHz
Form Factor DIMM 288-pin
Slots 24 (total) / 23 (empty)
Features Registered, dual rank, slots 13 - 24 are available in two-processor configuration only, HPE SmartMemory
Configuration Features 1 x 32 GB
RAM Supported 3 TB Load-Reduced - ECC ¦ 1.5 TB registered - ECC ¦ 192 GB Non-Volatile - ECC ¦ 6 TB - HPE Persistent Memory - Optane DC Persistent
Hard Drive
Type No HDD
Storage Controller
Type 1 x RAID - PCIe 3.0 x8
Controller Interface Type SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name HPE Smart Array P408i-a SR Gen10
Channel Qty 8
RAID Level RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Buffer Size 2 GB
Optical Storage
Type No optical drive
Monitor
Monitor Type None.
Graphics Controller
Video Memory 16 MB
Video Interfaces VGA
Networking
Ethernet Ports 4 x Gigabit Ethernet
Ethernet Controller HPE 366FLR
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller Integrated Lights-Out 5
Expansion / Connectivity
Bays 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots 1 (total) / 1 (free) x microSD Card (internal) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 0 (free) x FlexibleLOM
Interfaces 3 x USB 3.0 (1 front, 2 rear) ¦ 1 x VGA ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 1 x HPE iLO (service port)
Miscellaneous
Included Accessories Cable management arm, 4 standard fans, SFF Easy install rails
Compliant Standards WEEE, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Power
Device Type Power supply - hot-plug
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Installed Qty 1
Max Supported Qty 2
Voltage Required AC 120/230 V (50/60 Hz)
Power Provided 800 Watt
80 PLUS Certification 80 PLUS Platinum
Manufacturer Warranty
Service & Support Limited warranty - parts and labor - 3 years - on-site
Dimensions & Weight
Width 17.5 in
Depth 28.8 in
Height 3.4 in
Weight 32.54 lbs
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 8 - 90% (non-condensing)
